Description: Solid-state, remote-controlled line preamplifier with: 2 balanced inputs, 2 unbalanced inputs, balanced and unbalanced outputs; 66-step FET-switched volume control with 1dB step size; integral Ayre power-line RFI filter; and Theater mode. Frequency range: DC–200kHz. Maximum voltage gain: 4dB unbalanced, 10dB balanced. Maximum input level: 4V RMS unbalanced, 8V RMS balanced. Input impedance: 20k ohms unbalanced, 40k ohms balanced. Output impedance: 55 ohms unbalanced, 110 ohms balanced. Power consumption: 10W.
Dimensions: 17.25″ (440mm) W by 4.75″ (120mm) H by 13.75″ (350mm) D. Weight: 25 lbs (11.5kg).
Finish: Black- or natural-anodized aluminum.
