Specification

Configuration 4 way 5 driver system

Cabinet materialGlass reinforced balsa cored sandwich composite

Standard cabinet colourMulti component high gloss automotive

Bespoke cabinet colourBespoke colour options available on request

Drive units

HF: D26 — 26mm metal dome unit with Tapered Tube loading

Mid: D50 — 50mm metal dome unit with Tapered Tube loading

Lower mid: C125S — 125mm with Tapered Tube loading

Bass: C135—2 x 135mm alloy cone unit with short-coil long-gap motor design

Sensitivity87dB @ 2.83Vrms at 1.0 meter on axis

Impedance (�)6 nominal, 4 minimum,low reactance

Frequency range (Hz) – 6dB points: 33 – 36,000 Hz

First D26 Break Up mode:44,000 Hz

Frequency response36 – 33,000Hz +/- 2dB on reference axis

Harmonic distortion (2nd and 3rd harmonics)< 0.5% over frequency range

Cross over frequencies (Hz)220, 880, 3500

Power handling (music program) watts rms 800

Loudspeaker dimension 1161mm (H) x 341mm (W) x 578mm (D)

Net weight36kg
